AOS’s all-new power solution, tailor-made for Intel Panther Lake/Wildcat Lake.
2026-05-21

Under the synergistic effect of the new digital multiphase controller and intelligent power level, the static power consumption of the system has been reduced to the top level in the industry, allowing the battery life of mobile devices to be extended by up to one hour.

Alpha and Omega Semiconductor Limited (AOS, NASDAQ: AOSL), a renowned power semiconductor and chip solutions provider that integrates design, research and development, production, and global sales, announced the launch of a series of new digital multiphase controller product families: AOZ71049QI, AOZ71149QI, and AOZ71146QI. These 4-output channel controllers are specifically designed for the Intel IMVP9.3 Vcore power architecture. When used in conjunction with AOS industry benchmark DrMOS and Smart Power Stage (SPS) technology, they will provide a complete power solution for the latest Intel Panther Lake and Wildcat Lake mobile processor architectures.

Outstanding performance of hybrid architecture

The inherent advantages of precise and flexible digital tuning and analog efficiency
AOS's proprietary Advanced Transient Modulation (A2TM) technology endows the AOZ71049QI series with a unique hybrid advantage: it cleverly bridges the gap between digital flexibility and analog efficiency, combining variable frequency hysteresis peak current mode control with advanced phase current detection technology. This achieves ultra fast transient response and maintains excellent current balance under both transient and DC load conditions. One of the core differentiating advantages of this series is its extremely low static power consumption across all Intel IMVP 9.3 power states - providing longer battery life for the next generation of laptops and ultrabooks by minimizing power loss.

Easy control of performance and temperature

Simple design and excellent heat dissipation efficiency

To simplify the development cycle, users can directly write configurations into the controller's Multi Programmable Memory (MTP) through an intuitive and easy-to-use graphical user interface (GUI). This design not only eliminates the tedious manual welding rework during the debugging phase, but also effectively reduces the overall Bill of Materials (BOM) cost.

When used in conjunction with AOZ52986QI Smart Power Stage (SPS), the entire solution can unleash peak performance. The device adopts a compact QFN3x4 package and symmetrical pin layout, which not only greatly simplifies the PCB design process, but also effectively reduces parasitic inductance by 5%.

The biggest challenge facing SoC power supply in the field of mobile applications has always been how to strike a balance between performance and power consumption. Our AOZ71049 series adopts innovative control solutions that not only meet Intel's most stringent requirements with ease, but also achieve the industry's lowest static power consumption. For end users, this means that compared to competing solutions, the battery life can be extended by an additional 30 to 60 minutes.

Wayne Lee

Marketing Director of AOS Power IC

Technical Highlights

Multiphase controller

AOZ71049QI / AOZ71149QI / AOZ71146QI

Flexible configuration: Supports up to 4+2+1+2 phase outputs, covering multiple key power domains including core (IA), graphics (GT), auxiliary (SA), and low-power core (LPCORE).

Ultra low static current: In PS0 operating mode, when configured as 3+2+1+1 phase, the static current is as low as only 5.9mA.

Intelligent management: integrating autonomous phase reduction and automatic DCM functions, intelligently optimizing power loss.

Wide compatibility: It can flexibly adapt to industry standard DrMOS from multiple suppliers, and also supports various power level solutions composed of driver and MOSFET combinations.

Acoustic noise suppression: Built in exclusive noise reduction function ensures that the system operates silently even when the load changes dramatically.

Intelligent Power Stage (SPS)

AOZ52986QI

Robust performance: Supports a wide voltage range of 2.7V to 22V and integrates a 30V high side MOSFET, significantly enhancing system reliability.

High current density: Supports 45A continuous output current, with a peak value of up to 80A.

Precision Monitoring: Integrated high-precision current and temperature monitoring functions, with a current monitoring accuracy of 3.5% and a temperature monitoring accuracy of 2%, providing accurate and reliable real-time data for system operation.

Space saving: Optimized for switching frequencies up to 1.5MHz, it supports the use of smaller peripheral components for compact design.
