TDK launches multiple PoDL expansion boards for SPE evaluation of analog components
2024-09-18
TDK Corporation (Tokyo Stock Exchange code: 6762) announced the launch of a series of 10BASE-T1L plug and play test boards, known as EVB-DLA-00x. These test boards have six power levels to choose from, suitable for single pair Ethernet (SPE) evaluation boards for analog components (ADI) EVAL-ADIN1100EBZ and EVAL-ADIN1110EBZ. SPE technology can provide seamless Ethernet connectivity from a single sensor to the cloud, making the creation of Industrial Internet of Things (IIoT) and Industry 4.0 networks easier.
The 10BASE-T1L Ethernet protocol can not only achieve data transmission rates of up to 10 Mbps within a range of up to 1000 meters, but also provide power supply, which is known as Data Line Power (PoDL). TDK can provide a variety of inductors for these applications, including common mode choke (CMC), isolation inductor (ICI), and differential mode inductor (DMI).
These three types of components have now been integrated into TDK's expansion board and can be directly inserted into the prototype connector of the analog component evaluation board, meeting different APL and IEEE 802.3kg-2019 power level requirements, with a maximum power supply current of 1810 mA. These expansion boards are plug and play, making it convenient for designers in industrial and building automation applications to use analog component evaluation boards to start development work at any time.
Features and Applications
Main applications
Industrial automation
Process automation
Building automation
Main features and advantages
Designed specifically for different APL and IEEE 802.3 g-2019 power level requirements
• Attenuation complies with IEEE 802.3 g-2019
• Can cover a complete inductor product line of 10BASE-T1L
• High reliability components
• High current capability
About TDK Corporation
TDK Corporation, headquartered in Tokyo, Japan, is a leading global electronics company that provides electronic solutions for the smart society. TDK is built on a foundation of expertise in materials science, always staying at the forefront of technological development and embracing social change with the slogan 'technology attracts the future'. The company was founded in 1935 and specializes in ferrite, a key material used in electronic and magnetic products. TDK's comprehensive and innovation driven product portfolio includes passive components such as ceramic capacitors, aluminum electrolytic capacitors, thin-film capacitors, magnetic products, high-frequency components, piezoelectric and protective devices, as well as sensors and sensor systems (such as temperature and pressure, magnetic and MEMS sensors). In addition, TDK also provides products such as power and energy devices, magnetic heads, etc. The product brands include TDK, EPCOS, InvenSense, Micronas, Tronics, and TDK Lambda. TDK focuses on markets such as automotive, industrial and consumer electronics, as well as information and communication technology. The company has a network of design, manufacturing, and sales offices in Asia, Europe, North America, and South America. In the fiscal year 2024, TDK's total sales amounted to $14.6 billion, with approximately 10000 employees worldwide.
