Littelfuse Magnetic Sensor Product Portfolio Expansion - High Precision TMR Angle Sensor
2025-08-28
The new full pole sensor provides 0-360 ° angle measurement, better thermal stability, more flexible packaging, and is suitable for harsh environments
Littelfuse Corporation (NASDAQ: LFUS) is a diversified industrial technology manufacturing company dedicated to powering a sustainable, interconnected, and safer world. Today, it announced the launch of two new TMR based magnetic angle sensors, LF53466 and LF53464, which can provide high-precision 0-360 ° angle measurements with minimal thermal drift in harsh environments.
Both sensors use tunneling magnetoresistance (TMR) technology and a dual push-pull Wheatstone bridge configuration, each with four high-sensitivity sensing elements for accurate angle detection along the X and Y axes. These sensors have excellent thermal stability, wide power supply voltage compatibility, and higher measurement accuracy, making them a powerful alternative to Hall effect devices.
LF53466 adopts standard TSSOP8 packaging, providing precise angle sensing with an error of less than 0.8 ° within the magnetic field range of 200-800 Gs. This product is highly suitable for industrial and automotive applications where mechanical solder joints are sturdy and easy to inspect, such as steering wheel angle sensors, pedal position sensors, and non-contact potentiometers.
LF53464 adopts a compact LGA8L package, which can achieve greater accuracy angle error below 0.6 ° and has a larger sensing distance, making it compatible with smaller and lower cost magnets. It is also very suitable for applications with limited space, such as rotary encoders, knobs, and valve position sensing, as well as consumer devices, including power tools and appliances.
Main functions and features
0-360 ° angle measurement with X-Y axis sensing;
TMR technology can improve magnetic sensitivity;
Low angle error:<0.8 ° (LF53466TMR),<0.6 ° (LF53464TMR);
Excellent thermal drift compensation ensures stable performance;
Wide power supply voltage range, flexible system design;
Differential output ensures stable signal integrity;
Two packaging options: TSSOP8 (LF53466-08TMR) for easy assembly; LGA8L (LF53464-08TMR) is suitable for miniaturization design.
Julius Venckus, Global Product Manager for Sensors, stated, "These new TMR all pole sensors open the door to broader industrial, mobile, and consumer markets, significantly expanding Littelfuse's magnetic sensing product portfolio. LF53466 and LF53464 combine high precision, thermal stability, and packaging flexibility to enhance applications that require speed control and angle detection. ”
Target Market and Applications
Industrial automation and robotics technology: used for rotating position sensors, absolute angle detection, and control of robotic arms or longitudinal rods in factory equipment and intelligent machinery;
Motor and off-road vehicles: steering angle, pedal position, and motor control for electric bicycles, 2/3 wheelers, and construction or off-road electric vehicles;
Consumer and smart devices: Compact sensors in power tools, smart thermostats, and appliances, including knob and valve position sensing, provide intuitive user interfaces;
Precision control system: high-resolution rotary encoder, non-contact potentiometer, and angle sensor, used for motor feedback, valve drive, and HMI (Human Machine Interface) applications.
Supply situation
This product is provided in the form of rolls, with a minimum order quantity of 3000 pieces for LF53466 and 4000 pieces for LF53464. Accept sample requests through globally authorized Littelfuse distributors. To learn about the list of authorized Littelfuse distributors, please visit Littelfuse.com.
